Hard Effects
Polar rippling dots with a fade to dark at the bottom
A picture built in steps: polar coordinates, then ripple the space, then draw dots, then color it, then finish with a fade to dark at the bottom. Every step is listed below with its exact numbers.
How this challenge works
You write a fragment shader that draws the picture above, live in your browser. A match bar shows how close you are, and the score combines accuracy, code size (the par is 378 characters in Unity (Built-in)) and GPU speed. Work in HLSL, GLSL, WGSL, Metal or Godot and export the result when you are done.
The numbers you need
- Space
p = (uv - 0.5) * float2(aspect, 1.0)- Step 1: Polar coordinates
p = float2(atan2(p.y, p.x) / 3.1415927, length(p) * 2.0) (x = angle from -1 to 1, y = distance)- Step 2: Ripple the space
p.x += 0.06 * sin(p.y * 6.0)- Step 3: Pattern
g = p * 7.0; f = frac(g) - 0.5; m = 1.0 - smoothstep(0.21, 0.24, length(f))- Step 4: Colors
lerp(float3(0.13, 0.07, 0.05), float3(0.9, 0.7, 0.38), m)- Step 5: Finish
col *= 0.7 + 0.3 * uv.y
Solve it in your language
Unity (Built-in), Unity (URP), Unreal, Shadertoy / WebGL, OpenGL (LWJGL, raylib), three.js, GameMaker, LÖVE (Lua), Godot, Apple (iOS, macOS), WebGPU / Bevy.
Start coding
